‼️GRIPS ODI LONGNECK ST 9.99€‼️

KIT CADRE BOMBTRACK HOOK EXT C NEW

Name: KIT CADRE BOMBTRACK HOOK EXT C NEW
Brand: BOMBTRACK
SKU: CADR07893344
Price: 1899.00 EUR
Availability: OutOfStock

BOMBTRACK FÉVRIER 2024

TAILLE

1 899,00 €

Non dispo pour le moment

Description du produit « KIT CADRE BOMBTRACK HOOK EXT C NEW »

Un cadre dynamique et passe partout!

Model	HOOK EXT C
Color 1	Glossy Metallic Black
Color 2	Glossy Dark Green
Frame	TORAY T700 / T800 Hi-Mod carbon, TA, rack / fender mounts, 68 mm T47 BB shell
Fork	Full carbon, TA, 1.1/2'' - 1.1/8'', triple cage mounts (can double as fender mounts),internal hub dynamo cable routing
Headset	Sealed integrated aheadset, 1.1/2'' - 1.1/8''
Through axle	12 x 100 mm / 12 x 142 mm
Seat clamp	BOMBTRACK PRIME 31.8 mm
Rack	-
Weight frameset	1260 frame (size M, incl. TA, hanger, cable guides) / 600 g fork (300 mm steerer, incl. TA)
Maximum rider weight	105 kg incl. luggage
ASTM riding condition	2

Model	HOOK EXT C
BB standard	T47 - 68 mm shell width
Headset standard (S.H.I.S.)	IS42 / 28.6 \| IS52 / 40
Headset crown race angle	36°
Fork max tire clearance w/o fender	650B x 52C / 700C x 45C
Frame max tire clearance w/o fender	650B x 52C / 700C x 45C
Maximum chainring clearance 1x	46 T with 45 mm chainline
Maximum chainring clearance 2x	50 / 34 T with 43.5 mm chainline
Seat post diameter	27.2 mm
Seat clamp diameter	31.8 mm
Front derailleur clamp diameter	FD direct mount
Brake mount front	FM
Brake mount rear	FM
Maximum rotor clearance front	160 mm
Maximum rotor clearance rear	160 mm
Front through axle	12 mm x 100 mm, 1.5 thread pitch
Rear through axle	12 mm x 142 mm, 1.5 thread pitch
ISO testing standard	Road
Derailleur hanger	BT-DH-013
Frame small parts	BT-CR-014 / BT-CR-015
Through axle front	BT-TA-F-601
Through axle rear	BT-TA-R-603
